12
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
EN
Warning:
EN 81-20 denes the technical requirements for lift construction.
EN 81-50 provides the framework for design and testing of lift components
6.3.2 Safety specication
Safety outputs 13-14 and 23-24
Safe state of outputs Open
Safety inputs S12-S11 and S22-S21
Safe state of inputs Open
Safety function
1. The release of either one or both safety inputs will release the safety
outputs.
2. The re-activation of the safety outputs is only possible after the release
of both safety inputs.
6.3 Technical data
6.3.1 Timing specication
Activation time Ta < 160ms
Release time Tr
Double channel mode: < 20ms
Single channel mode: < 160ms
Simultaneity Ts Infinite
Monitored manual start delay Td > 500ms
Information:
• The start/restart command must be installed outside the danger area in a position where the concerned
danger and entire working area are clearly visible.
• It must not be possible to reach the start/restart command from the inside of the danger area.
Attention:
Use in manual start mode is mandatory where the safety device controls an access protecting a danger
zone. This is to prevent a situation in which, once a person has passed through the opening, they could
remain in the danger zone without being detected. Failure to comply with this rule may result in serious
risks to people exposed.
6.3.3 Safety parameters
ISO 13849-1 Safety Category Cat. 4
ISO 13849-1 Performance Level PL e
DIN EN 81-20 Certied
DIN EN 81-50 Certied
MTTF
D [a] 420,8
PFH
D [1/h] 1,85 E-10
DCavg 99%
ß 5,00 E-02
ß
D 2,00 E-02
6.3.4 Power supply
Power supply
24 Vdc ±10%, 2 W, Class 2
24 Vac -15/+10% 50÷60 Hz, 4.5 VA, Class 2
Overvoltage category III
Short circuit protection internal PTC
Rated insulation voltage 4 kV
