7.3.6 Outputs
Number of NO safety outputs 3
Number of NC auxiliary outputs 1
Type Voltage free contact output, relays with forcibly guided contacts
Max current rating - single output: @ 60°C (140°F) operating temperature:
EN60947-5-1
AC 1: 250V / 6A / 2000 VA - AC 15: 230V / 3A
DC 1: 24V / 6A - DC 13: 24V / 2.5A / 0.1 Hz
UL508 Pilot duty: B300 / R300
Max. total current Σ Ith²:
Spacing between modules ≥100mm: 72A² @40°C (104°F) ambient
temperature
Modules mounted stacked: 26A² @25°C (77°F) ambient temperature
Please refer to the derating curves in chapter 12
EN60947-5-1
UL508 Pilot duty: B300 / R300
Mechanical life > 10
7
operations
Electrical life AC1 (360 s/h) ~ 10
5
operations
7.3.5 Inputs
Number of safety channels 2
Safety inputs (contact inputs) S11-S12 and S21-S22
Loop resistance Max. 1 kΩ
Input current Typical 5 mA
7.3.7 Compatibility and conformity
Low Voltage Directive 2014/35/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
EMC Directive 2014/30/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
Machinery Directive 2006/42/EC EC type examined by TÜV - Cert. no. 44 205 15058308
EN ISO 13849-1
Safety of machinery - safety related parts of control systems - General
principles for design
EN60204-1
Safety of machinery - Electrical equipment of machines - General
requirements E-stop category 0
EN 61326-3-1
Electrical equipment for measurement, control and laboratory use. EMC
requirements. Immunity requirements for safety-related systems and
for equipment intended to perform safety-related functions (functional
safety) - General industrial applications
Lift Directive 2014/33/EU EU type examined by TÜV - Cert. no. 44 208 15058308
EN 81-20
Safety rules for the construction and installation of lifts.
Part 20: passenger and goods passenger lifts
EN 81-50
Safety rules for the construction and installation of lifts.
Part 50: design rules, calculations, examinations and tests of lift
components
EN 12015
Electromagnetic compatibility. Product family standard for lifts,
escalators and passenger. Emission
EN 12016
Electromagnetic compatibility. Product family standard for lifts,
escalators and passenger. Immunity
