34
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
EN
9.3.5 Inputs
Number of safety channels 2
Safety inputs (contact inputs) S11-S12 and S21-S22
Loop resistance Max. 30 Ω (eq. 2500m 1,5mm² Cu)
Input current Typical 30 mA
9.3.6 Outputs
Number of NO safety outputs 2
Number of NC auxiliary outputs 1
Number of PNP auxiliary outputs 1; PNP collector, 24 Vdc, min external resistive load 2.4 kΩ
NO and NC outputs type Voltage free contact output, relays with forcibly guided contacts
Max current rating - single output: @ 60°C (140°F) operating temperature:
EN60947-5-1
AC 1: 250V / 6A / 2000 VA - AC 15: 230V / 3A
DC 1: 24V / 6A - DC 13: 24V / 2.5A / 0.1 Hz
UL508 Pilot duty: B300 / R300
Max. total current Σ Ith²:
Spacing between modules ≥100mm: 72A² @40°C (104°F) ambient
temperature
Modules mounted stacked: 26A² @25°C (77°F) ambient temperature
Please refer to the derating curves in chapter 12
EN60947-5-1
UL508 Pilot duty: B300 / R300
Mechanical life > 10
7
operations
Electrical life AC1 (360 s/h) ~ 10
5
operations
9.3.7 Compatibility and conformity
Low Voltage Directive 2014/35/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
EMC Directive 2014/30/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
Machinery Directive 2006/42/EC EC type examined by TÜV - Cert. no. 44 205 15058308
EN ISO 13849-1
Safety of machinery - safety related parts of control systems - General
principles for design
EN60204-1
Safety of machinery - Electrical equipment of machines - General
requirements. Two-hand control type III
EN ISO 13851
Safety of machinery - Two-hand control devices - Principles for design
and selection
EN 61326-3-1
Electrical equipment for measurement, control and laboratory use. EMC
requirements. Immunity requirements for safety-related systems and
for equipment intended to perform safety-related functions (functional
safety) - General industrial applications
Approvals
