7
EN
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
3. Installation and environmental conditions
Warning:
MS1 must be installed in a control cabinet with a protection grade of at least IP54, otherwise dampness or
dust may lead to malfunction.
Warning:
Avoid installation during thunderstorms.
Danger!
If the safety module is tampered, it can no longer ensure the safety of the operator and the warranty is void.
Information:
Use the notch on the rear of the unit to attach it to a DIN rail.
Ensure the unit is mounted securely on a DIN rail (35 mm) by using a xing element (e.g. retaining bracket
or an end angle).
Information:
Do not dispose of the packaging in the environment.
Information:
MS1 must only be used within an ambient temperature range of -25 ÷ +60°C (-13 ÷ +140°F); UL: +40°C
(+104°F), away from any condensation or conducting uids. To avoid possible interference, keep the
connecting conductors separate from the power conductors.
