COMEPI MS1A31-024 - Outputs; Compatibility and Conformity; Environmental

40
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
EN
10.3.6 Outputs
Number of NO safety outputs 4
Number of NC feedback output 1
Outputs type Voltage free contact output, relays with forcibly guided contacts
Max current rating - single output: @ 60°C (140°F) operating temperature:
EN60947-5-1
AC 1: 250V / 6A / 2000 VA - AC 15: 230V / 3A
DC 1: 24V / 6A - DC 13: 24V / 2.5A / 0.1 Hz
UL508 Pilot duty: B300 / R300
Max. total current Σ Ith²:
Spacing between modules ≥100mm: 72A² @40°C (104°F) ambient
temperature
Modules mounted stacked: 26A² @25°C (77°F) ambient temperature
Please refer to the derating curves in chapter 12
EN60947-5-1
UL508 Pilot duty: B300 / R300
Mechanical life > 10
7
operations
Electrical life AC1 (360 s/h) ~ 10
5
operations
10.3.8 Environmental
Protection grade
IP40 on frontal part of the housing, IP20 on the terminals. The device
has to be installed in a cabinet with protection degree of IP54.
Pollution degree 2
Operating Temperature -25 ÷ +60°C (-13 ÷ 140°F), UL: +40°C (104°F);
Storage Temperature -30 ÷ +70°C (-22 ÷ 158°F)
Ambient humidity range R.H. ≤95% non condensing
10.3.7 Compatibility and conformity
Low Voltage Directive 2014/35/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
EMC Directive 2014/30/EU
EN 60947-5-1
Low-voltage switchgear and controlgear - Control circuit devices and
switching elements - Electromechanical control circuit devices
Machinery Directive 2006/42/EC EC type examined by TÜV - Cert. no. 44 205 15058308
EN ISO 13849-1
Safety of machinery - safety related parts of control systems - General
principles for design
EN60204-1
Safety of machinery - Electrical equipment of machines - General
requirements
EN 61326-3-1
Electrical equipment for measurement, control and laboratory use. EMC
requirements. Immunity requirements for safety-related systems and
for equipment intended to perform safety-related functions (functional
safety) - General industrial applications
Approvals
