35
EN
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
Information:
You must comply with the safety-related parameteres in order to ensure the required safety level for your
plant/machine. All the units which use a safety function must be considered when calculating the overall
safety level.
Cat 4; PLe, possible (also depending on the output wiring and the chosen trigger elements).
9.4 Wiring diagram
A1
A2
Y1 Y2 34
S11 S12
S21
S22
13
14
23
24
31
32
Feedback
control loop
L
Pwr 24V (+/~)
Pwr 24V (-/~)
S1 S2
24Vdc
Load > 2.4kΩ
M1
3~
M
K1
K2
N
9.3.8 Environmental
Protection grade
IP40 on frontal part of the housing, IP20 on the terminals. The device
has to be installed in a cabinet with protection degree of IP54.
Pollution degree 2
Operating Temperature -25 ÷ +60°C (-13 ÷ 140°F), UL: +40°C (104°F);
Storage Temperature -30 ÷ +70°C (-22 ÷ 158°F)
Ambient humidity range R.H. ≤95% non condensing
