COMEPI MS1A31-024 - E-Gate, Safety Limit Switch and Two Accesses Monitoring (Double Channel Mode); E-Gate, Safety Limit Switch and One Access Monitoring (Single Channel Mode)

31
EN
Rev. 1 | 01/2020 | MS Safety Module | © 2020 | Comepi srl
8.5.2 E-gate, safety limit switch and two
accesses monitoring (double channel mode)
A A cross circuit between the two channels will be recognized
B In case of a fault the safety outputs will switch OFF
L
Pwr 24V (+/~)
A2
X1 X2 X3
14 24 34 42
M1
3~
M
K1
K2
K3
N
Pwr 24V (-/~)
A1
S11 S12 S21 S22
13 23 33 41
Manual start
8.5.3 E-gate, safety limit switch and one
access monitoring (single channel mode)
A A cross circuit between the two channels will be recognized
B In case of a fault the safety outputs will switch OFF
L
Pwr 24V (+/~)
A2
X1 X2 X3
14 24 34 42
M1
3~
M
K1
K2
K3
N
Pwr 24V (-/~)
A1
S11 S12 S21 S22
13 23 33 41
Manual start
