CommScope ERA
®
CAP MX Medium Power Carrier Access Point Installation Guide M0203A5A_uc
Page 6 © November 2020 CommScope, Inc.
CAP MX Overview
CAP MX Connectors and Power LED
• Figure 2 shows the connectors and Power LED on a CAP MX that has one antenna connector.
• Table 2 on page 7 maps the callouts in Figure 2 and describes the connectors and Power LED.
Figure 2. Location of Connectors and Power LED on a CAP MX with One Antenna Connector
Do not remove caps from any of the connectors until instructed to do so.
