CommScope CAP MX Series User Manual

CommScope Era
™
Fiber Low Power Carrier Access Point Installation Guide M0201ANC_uc
Page 18 © June 2019 CommScope, Inc.
Plan and Prepare for a Fiber CAP L Installation
CAP L Dimensions
Use the dimensions shown in the section applicable to this installation to determine the space required at the
mounting site.
Mounting Dimensions for a CAP L with the Flat Mounting Bracket Kit
120mm
[4.72"]
42.75mm
[1.68"]
30mm
[1.18"]
24.11mm
[0.95"]
440mm
[17.32"]
406mm
[15.98"]
144mm
[5.67"]
205mm
[8.07"]
10mm
[0.39"]
4X
383.34mm
[15.09"]
512mm
[20.16"]
393.13mm
[15.48"]
2X
30.5mm
[1.2"]
114.28mm
[4.5"]
125.25mm
[4.93"]
