K-series OEM Board User Guide
10
There are other settings for onboard memory you can change based on your
requirements:
 Sample Interval: change the sample interval of observations, the maximum data
rate is 20Hz, the minimum is one observation per minute.
 Mask angle: disable the receiver to track satellites that below the mask angle.
You can set mask angle values for different constellations, which can reduce
serious multipath influence or low SNR.
 Data Log Session: 1) Manual means that the receiver keeps recording data in
one file until the receiver is turned off or its memory runs out; 2) if set to
1/2/3/4/12 hours, the data recorded will be saved in to a file every 1/2/3/4/12
hours.
 Data log: the default setting is manual mode. To log data in manual mode, send
the following commands.
For K5-series:
For K7-series:
Set static on
Saveconfig
Set emmc on
Saveconfig
Restart your OEM board
Set static on
Send set static off, if you finish recording
3.6 Data management
3.6.1 Raw Data Download
For K5-series OEM board, download data only from receiver to your PC through serial
port in CRU software.
1. Connect the OEM board to your PC as described before (see Chapter 3.1).
2. Click Folders to select download path
3. Click File Download in project menu to check all raw data on main window, or
