5
The CH6643E front panel LED indicators provide the following status information for
power, communications, and errors:
Not applicable ā LED does not
flash
Green: Power is properly connected
Scanning for a downstream
channel connection
Green: Downstream channel is
connected
Blue: Downstream channel is
connected with bonded channels
Scanning for an upstream channel
connection
Green: Upstream channel is
connected
Blue: Upstream channel is
