6
connected with bonded channels
Scanning for Internet connection;
transmitting or receiving data over
the Internet
Green: Connected to Internet
Telephone is off-hook; dialing or
call in progress
Green: Telephone is connected and
activated; on-hook
Amber: WPS function is enabled.
Green: Wi-Fi wireless interface is
active now.
Rear Panel
The CH6643E (shown above) rear panel contains the following cabling port and
connectors:
VoIP connection for a single telephone. Two sets of telephone can be
supported.
Use any Ethernet port to connect an Ethernet-equipped computer, hub,
bridge, or switch using an RJ-45 cable.
Activity LED - Green LED defines the activity of the Ethernet connector.
When LED is ON, this indicates that there is no data traffic and a
connection is stabilized.
When LED is FLASHING, this indicates that there is data being
