Compaq Armada E500 Series Maintenance And Service Guide

Removal and Replacement Procedures 5-15
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:36 PM
Part Number: 128679-006 File name: Ch05
5.9 Display Assembly
Display Assembly
Spare Part Number Information
15.0-inch, TFT, SXGA (Armada E500 only);
used only with config. codes beginning
with JFC.
201059-001
15.0-inch, TFT, XGA (Armada E500 only);
used only with config. codes beginning with
DX and FFH.
190806-001
14.1-inch, TFT, XGA; used only with config.
codes beginning with:
159532-001
CXX
CZQ
DC
DJD3
DJD4
DN81
DN82
DN84
DN85
DN9
DPB
DVR
FFD
FLC
FMX
FMZ
FWX
FVX
JFB
JFD
13.3-inch, TFT, XGA (Armada E500 only) 167133-001
DN83
DNN
FL5
FL6
FWB JFF JFH
13.3-inch, HPA, SVGA, (Armada V300 only);
used only with config. codes beginning
with DVP.
177749-001
12.1-inch, TFT, SVGA 159531-001
CXW
DJC
DJD1
DJD2
DNM
DVM1
DVM2
DVQ
FVY
FVZ
12.1-inch, HPA, SVGA, (Armada V300 only);
used only with config. codes beginning
with CXV
160536-001

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
