Compaq Armada E500 Series Maintenance And Service Guide

Illustrated Parts Catalog 3-1
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:34 PM
Pages: 14 Words: 1404 Template: c:\program files\microsoft office\templates\compaq\ref.dot
Part Number: 128679-006 File name: Ch03
chapter
3
I
LLUSTRATED
P
ARTS
C
ATALOG
This chapter provides an illustrated parts breakdown and a reference
for spare part numbers and option part numbers for the Compaq
Armada E500, E500S, and Armada V300 Series of Personal Computers.
3.1 Serial Number Location
When ordering parts or requesting information, provide the computer
serial number and model number located on the bottom of the computer
(Figure 3-1).
Figure 3-1. Serial Number Location

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
