Compaq Armada E500 Series Maintenance And Service Guide

5-36 Removal and Replacement Procedures
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:36 PM
Part Number: 128679-006 File name: Ch05
5.17 Fan
IMPORTANT: The fan must be replaced only by central repair depot
personnel.
Fan
Spare Part Number Information
Fan 159535-001
Removing the Fan
1. Prepare the computer for disassembly (Section 5.3) and, in the
order below, remove the following components:
■
Modem or modem/Network Interface Card (Section 5.5)
■
Touch button (Section 5.6)
■
Keyboard (Section 5.7)
■
Display assembly (Section 5.9)
■
LED board (Section 5.11)
■
Top cover (Section 5.12)
■
Front shield (Section 5.13)
■
Diskette drive (Section 5.14, Armada V300 only)
■
System board (Section 5.15)
2. Turn the system board bottom side up and position the board so the
I/O bracket faces forward.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
