5-2 Removal and Replacement Procedures
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:36 PM
Part Number: 128679-006 File name: Ch05
5.2 Disassembly Reference Chart
Use the chart below to determine the section number to be referenced
when removing components from the computer.
Disassembly Sequence Chart
5.3 Preparing the Computer for Disassembly
5.4 Computer Feet
5.5 Mini PCI Slot
Removing the Mini PCI Slot Cover
Installing a Modem or Modem/Network Interface Card
5.6 Touch Button
5.7 Keyboard
5.8 Memory
Removing a Memory Expansion Board
Installing a Memory Expansion Board
5.9 Display Assembly
5.10 Real Time Clock (RTC) Battery
5.11 LED Board
5.12 Top Cover
5.13 Front Shield
5.14 Diskette Drive (Armada V300 only)
5.15 System Board
5.16 Voltage Converter Board
5.17 Fan
5.3 Preparing the Computer for Disassembly
Perform the following steps before disassembling the computer. Consult
the computer reference guide, available as an electronic book on the
QuickRestore CD-ROM, for instructions on the steps below.
1. Undock the computer from the docking base.
2. Disconnect the AC Adapter and external devices.
3. Remove any battery packs inserted into the battery bay, DualBay
(Armada E500 only), or MultiBay.
