Compaq Armada E500 Series Maintenance And Service Guide

6-2 Specifications
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 11:53 AM
Part Number: 128679-006 File name: Ch06
Table 6-1
continued
U.S. Metric
Altitude (unpressurized)
Operating
Nonoperating
0 to 10,000 ft
0 to 30,000 ft
0 to 3048 m
0 to 9144 m
Shock
Operating
Nonoperating
10 G, 11 ms, half sine
240 G, 2 ms, half sine
Vibration
Operating
Nonoperating
0.5 G zero to peak, 10 to 500 Hz, 0.25 oct/min
1.5 G zero to peak, 10 to 500 Hz, 0.50 oct/min
NOTE:
Applicable product safety standards specify thermal limits
for plastic surfaces. The computer operates well within this range
of temperatures.
Table 6-2
15.0-inch SXGA, TFT Display
U.S. Metric
Dimensions
Height
Width
Diagonal
8.98 inch
11.97 inch
15.00 inch
22.81 cm
30.41 cm
38.01 cm
Number of Colors Up to 16.8 million
Contrast Ratio 150:1
Brightness 100 nits minimum, 120 nits typical
Pixel Resolution
Pitch
Format
Configuration
1400 × 1050
RGB Stripe
0.2175 × 0.2175 mm
Backlight Edge Lit
Total Power
Consumption 5.25 W

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
