Compaq Armada E500 Series Maintenance And Service Guide

2-14 Troubleshooting
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: The Integrity Group Saved date: 10/26/00 11:45 AM
Part Number: 128679-006 File name: Ch02
Using Compaq Diagnostics for Windows
1. Access Compaq Diagnostics for Windows by selecting
Start!Settings!Control Panel!Compaq Diagnostics.
2. To select a category, choose one of two methods:
■
Select the Categories menu, then select a category from the
drop-down list.
■
Select a category icon on the toolbar.
3. To run diagnostic tests:
a) Select the Test tab.
b) In the scroll box, select the category or device you want to test.
c) Select the Quick, Complete, or Custom test type.
d) Select the Interactive or Unattended test mode.
e) Select the Begin Testing button.
f) View test information by selecting a report from the Status,
Log, or Error tab.
4. To print the information or save it to a drive, select the File menu,
then select Print or Save As.
5. To exit, select File menu!Exit.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
