Compaq Armada E500 Series Maintenance And Service Guide

2-22 Troubleshooting
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: The Integrity Group Saved date: 10/26/00 11:45 AM
Part Number: 128679-006 File name: Ch02
Table 2-10
Solving Compact Disc and DVD-ROM Problems
Problem Possible Cause Solution
Drive cannot read a
disc
Disc is not properly
seated in the drive.
Open the loading tray,
insert the disc, then close
the tray.
Disc is loaded in the
loading tray upside
down.
Open the loading tray,
turn over the disc (label
facing up), then close the
tray.
Disc has a scratch
on its surface.
Insert a different disc.
CD-ROM drive or
DVD-ROM drive is
not detected by the
computer.
Drive is not
connected properly.
If you are running a
version of Windows that
was preinstalled by
Compaq, remove the
drive from the MultiBay
and reinsert it.
If you are running a
version of Windows that
was not preinstalled by
Compaq, turn off the
computer. Then remove
the drive from the
MultiBay and reinsert it.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
