Product Description
Maintenance and Service Guide 1–7
The external components on the right side of the computer
are shown below and described in Table 1-2.
Right-Side Components
Table 1-2
Right-Side Components
Item Component Function
1 Optical drive Reads an optical disc.
2 USB ports (2) Connect optional USB devices.
3 RJ-11 (modem) jack Connects a modem cable.
4 Power connector Connects an AC adapter.
5 Security cable slot Attaches an optional security cable to the
computer.
✎
The security cable is designed to act
as a deterrent, but it may not prevent
the computer from being mishandled
or stolen.
