Removal and Replacement Procedures
Maintenance and Service Guide 5–45
6. Remove the two Phillips PM2.0×4.0 screws 1 and the
Phillips PM2.5×9.0 screw 2 that secure the top cover to
the computer.
Removing the Top Cover Screws, Part 3
7. Lift up the front edge of the top cover and remove it.
Removing the Top Cover
Reverse the above procedure to install the top cover.

Compaq Presario V3000 Specifications

General

Wireless	802.11b/g
Audio	Altec Lansing speakers
Battery	6-cell Lithium-Ion
RAM	Up to 2 GB DDR2 SDRAM (expandable)
Display	1280x800
Graphics	Intel GMA 950
Operating System	Windows Vista
Optical Drive	DVD±RW
Ports	3x USB 2.0, VGA, S-Video, RJ-45, RJ-11, headphone/microphone jacks
Card Reader	5-in-1
Networking	10/100 Ethernet
Processor	Intel Core 2 Duo
Storage	120GB HDD
