Chapter 1 Product Overview
4
1.4 Panel Features
Features Status and Indication
Steady Green The port is connected to the switch.
Blinking Green The port is transmitting or receiving data.
1
LNK/ACT LEDs
Off There is no connection established in the
network.
Steady Amber The port is operating in Full Duplex mode.
Off The port is operating in Half Duplex mode.
2
FDX/COL LEDs
Blinking Amber Collision occurs in the network segment of
the respective port.
Steady Green Power is supplied to the switch. 3
Power LED
Off No power is supplied to the switch.
4
Console Port
A serial 9 Pin (DB9) RS232 straight socket is connected to PC
COM Port for monitoring the switch.
5
24 RJ45
Management Ports
Connect to web-browser via RJ45 UTP/STP network cable
• 10Base-T
• 100Base-TX
• Auto-negotiation
6
Open Expansion
Module Slot
Types of Optional Module used:
• SXM1000T/2: 2 Gigabit Copper Module
• SXM1000T/GBIC: 1 Gigabit Copper + 1 GBIC (3.3V) slot
7
Power Socket
Flexible power input (range 100VAC ~ 240VAC, 50~60Hz)
