Chapter 3 Network Applications
9
3.2 Segment Bridge
For enterprise company, bulky data broadcasts are constantly processed. Compex
SXP2224WM is ideally suitable for department users to connect to the corporate
backbone.
From the illustration shown below, Compex SXP2224WM is attached to a uplink
backbone. Two Ethernet switches are connected to Compex SXP2224WM. All
devices in the network can communicate with one another through Compex
SXP2224WM. A server is connected to the switch to allow users from accessing the
data on the server.
Figure 3.2a Department Bridge Application
PC 1 PC 2
PC 3
Server
Printer
Server
Compex
SXP2224WM
PC 4 PC 5 PC 6
Backbone Link
Gigabit Port
10/100Mbps
Port
Switch 1
Switch 2
