Statox 503 Control Module
Issue 10 / 2018 Page 43 of 46
Operating the Statox 503 with Statox 501 ARE or HRC Sensor
The catalytic sensors type Statox 501 ARE or HRC are considered as type A elements, see IEC 61508-2, section
7.4.4.1.2. The failure rates of these sensors has been evaluated from return shipments of the recent 15 years.
They were evaluated by SGS-TÜV Saar GmbH (Report No. M0PE0001).
Sensor λ
s
[FIT] λ
du
[FIT] λ
dd
[FIT] SFF [%] T
Proof
[h]
PFD
(0,5
*
T
Proof
*
λ
du
)
ARE / HRC
0 1002,1 2818,3 73,77 4380 2,19 x 10
-3
At a hardware failure tolerance of 0 and 6 month prooftest interval SIL 2 compliance is given for ARE/HRC
sensors (see IEC 61508-2, Table 2).
A prooftest of a Statox 501 ARE / HRC sensor head must be done together with the connected Statox 503
control module. For this test, span gas must be used.
Inhibit peripheral alarm devices in order to avoid false alarms.
Sensor head and sensor must be checked for pollution and damage.
The span gas concentration must be above the alarm thresholds. Use the original test gas adapter.
Check all alarm functions.
If necessary perform a calibration see chapter 6.2
Reactivate peripheral alarm devices.
Observe the ambience specifications of the ARE/HRC sensor heads and their IP rating.
