UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Front Panel Operation Revision 3
6–18
Converter Temp = +30.0C ▲
IFLO Tuning = 0.38V ▼
Synth Tuning: Sum=0.32V ▲
Coarse=06.0V Fine=03.5V ▼
Press ENTER or CLEAR to continue.
6.2.5 (SELECT:) FAULTS Menu Branch
The MASK selection is disabled in redundancy systems.
CURRENT STORED MASK
Use the keys to select CURRENT, STORED, or MASK. Press ENTER.
6.2.5.1 (FAULTS:) CURRENT
Four read-only information screens are provided to monitor a number of
operating parameters and return back whether the parameters are OK
(operating within normal ranges), or FT (currently faulted). These examples are
provided for reference only – the data varies depending on the operating
conditions for the system in use:
Power Faults: 15VDC=OK ▲
14VDC=OK VCC=OK ▼
IFLO Lock Detect = OK ▲
▼
Synth Faults: SumLD=OK ▲
FineLD=OK CoarseLD=OK ▼
