UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Installation and Startup Revision 3
3–8
4. Continue to slide the unit into the equipment rack to its final operating
position. Then, use four user-provided screws to secure the unit to the
equipment rack’s right and left threaded front rails (through the front
panel slots).
3.3 Connect Prime Power Connection
An IEC-60320 Type C13 (female) three-prong plug power cord for 90-125VAC or
205-240VAC power sources is provided with the converter. This detachable
power cord mates with the AC Prime power receptacle on the rear of the
converter chassis.
3.4 Connect External Cables
Proceed to connect all external cables to the connectors outlined in the next
chapter (Chapter 4. FRONT AND REAR PANEL CONNECTIONS). Should difficulties
occur, call Comtech EF Data Customer Support for assistance.
