Comtech EF Data UT-4505 - UTILITY:) SLOPE Submenu; UTILITY:) LAMP-TEST Submenu

UT-4500 Series C- and Ku-Band Up Converters MN/UT4500.IOM
Front Panel Operation Revision 3
6–27
6.2.7.6 (UTILITY:) SLOPE Submenu
Converter slope
adjustment = 0.0
Set your converter slope adjustment value. Use the   keys to select a digit,
and then use the  keys to change that digit. The default converter slope
adjustment is 0.0, with allowable values from 0.0 to 1.0. Press ENTER.
6.2.7.7 (UTILITY:) LAMP-TEST Submenu
Start Lamp Test?
No Yes
Use the   keys to select No or press CLEAR to exit this submenu. Otherwise,
select Yes and press ENTER to continue. The test begins with this message:
Lamp Test in Progress
Please Wait
The front panel runs through a series of diagnostics: the LED array cycles, and
then the VFD generate a series of test patterns.
The LEDs and VFD return to their previous display state upon successful
completion of the test. Once the test has run, press CLEAR to return to the main
menu.
