Unpacking the Boxes
The MDC comes fully assembled on a mobile drying cart. You should have
received the following components:
1 Carefully remove the dryer and components from the shipping container.
The vacuum receiver and material inserts will be on the built-in holders on the
drying cart. The RTD probe and extension cable may have been shipped inside
the dryer’s electrical enclosure.
2 Remove all packing material, protective paper, tape and plastic. Be sure to
remove the plastic tie and wrap that protects the desiccant tank and bed plate
assembly during shipment.
(continued)
Vertical conveying tubes
RTD probe
Direct feed
vacuum receiver
Viewing chamber
and demand sensor
Material inserts
Two lengths of flexible
conveying hose
Drying
hopper
Dryer
Pump
Dust
Collector
Vacuum receiver
mounting bracket
Virgin
1” opening
Regrind 1.25” opening
Demand sensor
cable
To Next Page
