Conair 100 - Refilling the Desiccant Tanks

6-26 l Troubleshooting
Refilling the Desiccant Tanks
When desiccant becomes clogged or contaminated, you should replace the des-
iccant in all three tanks to ensure optimum performance.
1 Remove the desiccant tank from the carousel.
See “Replacing Desiccant Tanks.”
2 Remove the the tank end plate.
Remove the six 10-32 self-tapping screws from the end plate.
3 Remove the screen cap.
Remove the two 1/4-20 nuts from the center post and pull the screen cap out.
4 Remove the old desiccant.
5 Replace the gasket on the flange, if necessary.
6 Fill the tank with fresh desiccant.
Fill the tank with the weight of desiccant indicated in the following table.
Model Desiccant Weight
15 & 25 1 lb. (0.37 kg)
50 2 lb. (0.75 kg)
75 3 lb. (1.12 kg)
100 4 lb. (1.49 kg)
(continued)
