NOTE: If your mounting
surface does not match
the standard bolt pat-
terns available, you will
need an adapter. You
can make an adapter
using the dimensions
provided or purchase
one from Conair.
❒❒
A mounting surface that will support the weight of the dryer, support
frame, and a fully-loaded hopper, or just the fully-loaded hopper. See the
specifications tables for weights and volumes.
❒❒
Material and conveying lines installed. If you plan to use vacuum or
compressed air loaders to fill the hopper, install conveying lines to the drying
hopper location.
2 Drill and tap mounting holes or make adapter.
Available discharge assemblies and slide gates fit mounting surfaces with
these bolt patterns and diameters.
3
Description
✐
Preparing for Installation (continued)
