4
O p e r a t i o n
C o n t r o l Fun c ti o n D es c ri p ti o ns -
S t a n d Al o ne Co n f i g u r a t i o n
( c o n ti n ue d )
Trending
To access the Trending screens:
1 Press the Trending button
from the Home screen.
The Trend Selection screen allows
you to choose which trending
screens you would like to view.
From this screen, you can choose to view:
• Dryer Air Temperature Trend
• Dryer Dewpoint Trend
• Dryer Material Temperature Trends
Trending Screen Navigation
Each trending screen will allow the user to scroll
through data. When the screen first opens, it will be
displaying a two (2) hour window, and will have saved
the data for the last seven (7) day period. The scroll
buttons near the bottom of the screen allow the user to
scroll back to an earlier time or forward to the present
time, or jump immediately to live data. The user can
also touch any point on the trend line and the display
will show the data reading, date, and time for that spot
in the trend.
Scroll to the beginning or end
of the record.
Scroll back or forward one
point at a time (30 seconds).
Move to live data.
Zoom in (Instead of seeing 2 hours of trend in the window, you will see 1 hour,
30 minutes, 15 minutes, etc.)
Zoom out (Instead of seeing 2 hours of trend in the window, you will see 3
hours, 4 hours, 5 hours, etc.)
NOTE: Depending on your DC-T
configuration, and system securi-
ty, different users may not be
able to access the trending
screens. Also, if you do not have
Drying Monitor enabled, or the
Drying Monitor equipment at
your drying hoppers, you will not
be able to view Drying Monitor
Trends.
✐
O p e r a ti o n l 4 - 7 5
