107
MINI-DRIVER
HANDPIECE
E
4. To operate the handpiece, release the safety
and depress the trigger.
5. To remove a blade:
(a) Ensure the handpiece is in the
safe, or off position.
(b) Insert the wrench and turn
counterclockwise while simultaneously
pulling the blade out.
3.10.5 All Jacobs Chuck Attachments
1. To attach any Jacobs Chuck attachment,
reference “3.10.2 Connecting/Removing
Attachments” on page 102).
2. Insert the desired accessory into the chuck
and secure it with the appropriate key.
3.10.5.1 5/32” Jacobs Chuck (K110)
This attachment is designed to drive straight
plain shank twist drill bits, pins, and wires
compatible with the specifications below:
Specifications:
Jaw Cannulation: 0 - 4.0 mm
(0 to 0.156 in.)
(0 to 5/32 in.)
Through Cannulation: 4.0 mm
(0.156 in.)
(5/32 in.)
Associated Chuck Key: D298K
