The following table shows the A/D output value for several input signals.
Current
Channel 0-4
Voltage
Channel 0-4
Voltage
Channel 5
A/D Output
0mA 0V 0V 0
1.22µA 0.305mV 0.001V 1
4mA 1.0V 3.277V 3277
10mA 2.5V 8.192V 8192
20mA 5.0V 16.384V 16384
39.999mA 9.9997V 32.767V 32767
