Typically 125mW (at 12V) during sleep mode.
Typically 360mW (at 12V) during normal operation. LEDs
off, no expansion.
6.5W maximum.
Output capacity
5V at 0.4A capacity
5V at 55mA required by 5207 controller
5V at 0.35A (current limited) on COM2 and the I/O
expansion
5V at 0.25A (current limited) on COM3
Vloop: 24V at 0.14A available for the 5 analog inputs and 2
optional analog outputs
Efficiency
85%, 12Vdc input, full load
14.6 I/O Capacity
5000 Series I/O
Expansion
Capacity
Maximum 40 I/O modules with a further limitation of 16
modules of any one type.
512 digital outputs using 32 point digital output modules
512 digital inputs using 32 point digital input modules
128 analog inputs using 8 point analog input modules
64 analog outputs using 4 point analog output modules
32 counter inputs using 4 point counter input modules
Example: 16 of the 32 point digital output modules + 16 of
the 32 point digital input modules + 8 of the 8 point analog
input modules would yield an expansion of 1088 I/O points.
14.7 Analog Inputs
Input Points
5 at 10V/20mA: 250Ω resistance user
configurable with jumper link.
1 at 32.768V
Resolution
15 bits over the 10V and 32.768V measurement
range.
14 bits over the 20mA measurement range.
Input Resistance
20kΩ for 10V inputs
60kΩ for 32.768V inputs
250Ω for 20mA inputs
Converter type
16 bit successive approximation
Accuracy
±0.1% of full scale at 25
o
C (77ºF)
±0.2% over temperature range
Type
single ended
Calibration
Calibration constants stored in on board
microcontroller EEPROM.
Normal mode rejection
27 dB at 60 Hz.
Over-scale Input Capacity
(without damage)
10V/20mA inputs clamped at 12V.
Transient: 2.5kV surge withstand capability as
per ANSI/IEEE C37.90.1-1989
SCADAPack LP Hardware Manual
May 26, 2006
43
