Figure 3-9 Surface mounting the size 4 drive
Figure 3-10 Surface mounting the size 5 drive
310mm (12.205in)
510mm
(20.079in)
298mm (11.732in)
258.6 0.5mm
(10.181 0.020in)
±
±
528.8
0.5mm
(20.819
0.020in
)
±
±
546.8mm
(21.528in)
18.4mm (0.724in)
25.7 0.5mm
(1.012 0.020in)
±
±
∅ 8.5mm
(0.335in)
∅ 8.5mm
(0.335in)
258.6 0.5mm
(10.181 0.020in)
±
±
25.7 0.5mm
(1.012 0.020in)
±
±
839.3
0.5mm
(33.043
0.020in)
±
±
310mm (12.205in) 298mm (11.732in)
857.3mm
(33.752in)
820mm
(32.283in)
18.4mm (0.72in)
∅ 8.5mm
(0.335in)
∅ 8.5mm
(0.335in)
