28 Commander SK Size 2 to 6 Getting Started Guide
www.controltechniques.com Issue Number: 2
3.5.1 Terminal sizes and torque settings
Table 3-4 Drive control and relay terminal data
Table 3-5 Drive power terminal data
To avoid a fire hazard and maintain validity of the UL Listing,
adhere to the specified tightening torques for the power and
ground terminals. Refer to the following tables.
Model Connection type
All Spring terminals
Model
size
AC terminals
DC and braking
terminals
Ground terminals
2
Plug-in terminal
block 1.5Nm
(1.1 lb ft)
Terminal block (M5
screws) 1.5Nm
(1.1 lb ft)
M5 stud 4.0Nm
(2.9 lb ft)
3
Terminal block (M6 screws) 2.5Nm
(1.8 lb ft)
6.0Nm
(4.4 lb ft)
4
M10 stud
15Nm
(11.1 lb ft)
M10 stud 12Nm
(8.8 lb ft)
5
6
Torque tolerance ±10%
WARNING
