MiniWarden/PoolWarden + (PLUS) Operation Manual • www.poolwardentraining.com • 15
Main Menu
The main menu is password protected and where all the configurations take
place. Press the Back button from the readings screen. If security is enabled
a password will be required.
Main Menu - Service
The Service Menu includes common items to service a pool including
manually feeding chemicals and calibration.
t Relay Manual Mode: Use the up and down arrow keys to scroll next to
the relay that needs to be put into manual mode. Press the Enter button
or the Right Arrow to put the selected relay into manual mode.
qIf the relay is currently ON, it will turn off for the manual time and then
go back into auto control.
qIf the relay is OFF, it will turn ON for the manual time and return to
auto control.
If the relay is OFF and in manual mode, it will return to auto.
t Clear Overfeed Times: If an overfeed timer has been reached it will only
clear/reset at midnight. There are times when servicing a pool that you
may want to clear the overfeed timers to stop an alarm from tripping or to
have the relay turn back on. This selection also clears the number of
times the relay has turned on during the day and the setpoint overfeed
timer.
Service Internet
TrueDPD Security
Relays Printer
CYA Setup
Main Menu
PH1 00:00:00 OFF
ORP1 00:00:00 OFF
Aux1 not used
Aux2 not used
PH2 00:00:00 Off
ORP2 00:00:00 Off
Aux3 not used
Aux4 not used
Relay Manual Mode
Cal ORP1 650 -16%
Cal pH1 7.7 -5%
Cal Temp1 78 +12%
Clear Cal ORP1
Clear Cal pH1
Clear Cal Temp1
Cal PPM1 3.4 -6%
Clear Cal PPM1
Calibration
qCycling power does not clear the overfeed timers.
The Setpoint Overfeed timers are also cleared when selecting the Clear Overfeed Times.
Relay Manual Mode
Clear Overfeed Times
Disable All Relays
Calibration Pool1
Calibration Pool2
Service Menu
Disable All Relays: Press Enter or Right Arrow to increment the hours off from 0 to 13. When the
relays are disabled, the readings screen bottom row will display “RLY Off 03:30:53” showing how much
longer until the relays go back to automatic control.
t Calibration Pool1 and Pool2: Select the desired pool to calibrate and
scroll to the sensor to calibrate. Manual Pool Measurements must be
taken to calibrate each sensor. For best results the pool should be at the
setpoints when calibrating. The percentage to the right of the current
reading is the amount of calibration and if it is at 99% that sensor is at the
maximum calibration and may need to be replaced. When calibrating,
press Back or Down Arrow to cancel and Enter to save the new
calibration. The current value displayed in the calibration screens is the
un-calibrated sensor.
qpH: Enter the manually measured pH value. A pH sensor can be
calibrated +/- 2 pH units.
qORP: If the sanitizer level is higher than desired and the pH is at the
setpoint then raise the ORP calibration slightly. If the sanitizer level is
lower than desired and the pH is at the setpoint then lower the ORP
calibration slightly. The ORP sensor can be calibrated +/- 200 mV.
ORP sensors are affected by cyanuric acid, pH and other factors and it
may take a few days to get it adjusted.
Calibrate pH1
Current: 7.7
Range 4.2 to 9.8
v-Cancel
Calibrate pH
qTemperature: Enter the manually measured temperature. A temperature sensor can be calibrated
+/- 25 degrees Fahrenheit. If the sensor need a lot of calibration it may need to be relocated closer
to the water inlet from the pool.
qPPM: If the TrueDPD is connected there will be a selection for calibrating the free chlorine. Refer to
appendix F for more information.
qClear Cal: Removes the calibration and the reading is immediately updated.
