MiniWarden/PoolWarden + (PLUS) Operation Manual • www.poolwardentraining.com • 24
Alarm Out Control Type
Alarm Out is where an external alarm can be connected to an Auxiliary
Relay. This may be needed in cases where a more pronounced sound or
light is needed.
t On if Alarm On - Yes: When set to Yes the Aux relay will be on if the
alarm light is on.
t Off if Flow Off - 1: The relay will be turned OFF if “No Flow” is detected in Flow Switch Input 1. Press
Enter to cycle between Flow Switch 1, 2, 3, 4 and none. If the circulation pump turns off at night you
may not want this additional alarm output to be on
t Off If Time < 00:00:00: Turn off if the time is less than the value. Use this command if you don’t want
notifications at night.
t Off If Time > 00:00:00: This is a time of day command. If not 00:00:00, the alarm out will be OFF for
the indicated time until midnight. Use this command if you don’t want notifications at night.
On if Alarm On Yes
Off if Flow Off FS 1
OffIfTime< 00:00:00
OffIfTime> 00:00:00
Alarm Out
Superchlorination
Use this relay control type to feed an increased amount of sanitizer once a
week or a couple times a week. This is a fixed feed and doesn’t turn off
based on chemical levels being reached.
t Manual Time 00:02:00: The manual time can be used to test the sanitizer
feed for super-chlorination.
t Day Of Week smtwtfs: Set the days of the week to perform super-
chlorination. Note: With this command it will be on the entire day, use the
Off if Time </> to limit the actual time of the day. To change the days
press numbers 1-7 to toggle a specific day. Note: The relay will be on the
entire day selected, use the commands below to set a specific time on the
selected days.
ManualTime 00:02:00
DayOfWeek smtwtfs
MaxTimeOn 00:00:00
MinTimeOff 00:00:00
OffIfTime< 00:00:00
OffIfTime> 00:00:00
Orp High Limit 700
PPM High Limit 0.0
Off if Flow Off FS 1
Super Chlorination
t MaxTimeOn: The relay will be on for this amount of time. Calculate how much chlorine to add and set
the time appropriately.
t MinTimeOff: After the relay has been on it will be off for at least this amount of time. Use this command
to spread out the chemical feed time.
t Off If Time < 00:00:00: Set the time to start the superchlorination.
t Off If Time > 00:00:00: Set the time to end the superchlorination.
t ORP High Limit 700: Turn off if the ORP exceeds this value.
t PPM High Limit 0.0: Turn off if the PPM exceeds this value.
t Off if Flow Off - 1: Do not super-chlorinate if the flow is off.
Water Level
Water Level is where a pool water fill can be connected to an Auxiliary Relay and configured in this menu.
If a water level switch is used it should be connected to Flow 2 for Pool1 or Flow 4 for Pool2. When the
water is below the switch level then water should be added. The flow switch can be either on when the
water is low or off when the water is low depending on the type of switch.
t Manual Time 00:02:00: Manual feed time.
t On if Flow On - none: The Aux Water Level Relay will be turned on if “Flow” is detected in a Flow
Switch Input. Set this command to the appropriate flow switch input if the switch is ON when the water
is low. Note: If setting the On if Flow On to a switch value, leave On if Flow Off set to none.
t On if Flow Off - none: Set this command to the appropriate flow switch input if the switch is OFF when
the water is low. Note: If setting the On if Flow Off to a switch value, leave On if Flow On set to none.
