MiniWarden/PoolWarden + (PLUS) Operation Manual • www.poolwardentraining.com • 22
Main Menu - Setup
The Setup Menu is where many of the main operating system features are
turned on or off. Please review and set each item according to your needs.
t Units: Press Enter to toggle between the English or Metric System. This
is for the display of temperature only.
t Pools (PoolWarden): Press Enter to toggle between single and dual
pool mode. This setting is normally entered by the factory when
PoolWarden is purchased.
Names Menu (PoolWarden Only)
§ Location: Enter a descriptive name for the location
§ Pool1: Enter a descriptive name, ex: Main Pool
§ Pool2: Enter a descriptive name, ex: Kiddie Pool
§ AUX1-4: Enter a descriptive name
t Aux1-4 (PoolWarden Only): The pH and ORP relays are fixed in what
they can control while the Aux relays have many types of equipment that
can be connected. See appendix A for more information and the control
types.
t Factory Defaults: Reset all settings back to factory defaults. Warning
screen to press “9” to proceed.
t pH/ORP Ctrl: Mixing or Cycle. WARNING: Changing the control type
resets all settings to factory default. See appendix B for more information
on cycle control. Warning screen to press “9” to proceed.
t TrueDPD: Enabled or Disabled. Only enable if the TrueDPD external
sensor box is installed and connected. WARNING: Changing this resets
the ORP and Alarm relays to factory default. Warning screen to press “9”
to proceed.
PoolWarden Setup no PPM
Units: English
Pools: 2 (Dual)
Names Menu
Aux1: Not Used
Aux2: Not Used
Aux3: Not Used
Aux4: Not Used
Factory Defaults
pH/ORP Ctrl: Mixing
TrueDPD: Disabled
Time Zone - Eastern
Unused Rly Cmds:Show
Alarm Deltas: On
P1 pH Lkout min/hr 0
P2 pH Lkout min/hr 0
MiniWarden Setup
Units: English
Name: MiniWarden
Pool1: Pool
Factory Defaults
pH/ORP Ctrl: Mixing
TrueDPD: Enabled
Time Zone - Pacific
Unused Rly Cmds:Show
Alarm Deltas: On
t Time Zone: Enter the appropriate time zone or the time will not be correct.
t Unused Rly Cmds: This setting makes the controller easier to program. When a relay setting is 0 that
setting is skipped. Ex. For pH control, if Base Setpoint = 0 there is no reason to even see that
command. Changing this setting to “Hide” will hide all of the commands that are 0 making the list of
settings shorter. This also makes changing the settings safer because if the setting “Base Setpoint = 0”
is not shown it can’t be accidentally changed.
t Alarm Deltas: Setting to “Yes” will use a value that is added to the setpoint as the alarm condition.
When changing the setpoint the alarm will remain a consistent value away from the setpoint. For more
information see the “Alarm 1 and 2 Setup” in the Relay Menu. Changing this will bring up the warning
screen to press “9” to proceed as it will reset all alarms to factory defaults..
t P1/2 pH LKout min/hr 0 (Poolwarden Only): When in pH lockout most controllers disable sanitizer
feed completely. The PoolWarden allows for a backup control when in pH lockout by feeding from 1 to
9 minutes every hour (0 disables). This feature isn’t included with the TrueDPD as the PPM
measurement will be in control.
