17
DEATH, INJURY, EQUIPMENT and PROPERTY DAMAGE
will result from improper installation of drain outlet lines.
Install free air vented drain lines as described in this manual.
Do not connect the MINI Combi/Oven-Steamer drain connection to
any drain material that cannot sustain 140
o
Fahrenheit.
Using drain material that cannot withstand 140
o
Fahrenheit can
result in injury, equipment damage, and property damage.
G. General Information for All MINIs
1. Keep the vents on the bottom and top of the MINI clear, clean, and free of obstruction.
2. The MINI must be level. Level the MINI from the bottom: Use the height adjustable legs of the
MINI and a level so the MINI is level front-to-back and side-to-side.
3. Do not store anything on top of a MINI.
4. Operating Clearances: Sides and Rear – 3”.
• Allow for sufficient distance if a "high heat source," (e.g. broiler) is located next to the MINI.
• Installation must comply with all
local fire and health codes.
5. Service Clearance: Above – 20”.
6. Keep the vents on the top and bottom of the MINI clear, clean, and free of obstruction.
7. The factory installed legs must be used and must not be removed.
H. Install Free Air Vented Drain Lines from the MINI to the existing Floor Drain
NOTE: This equipment is to be installed to comply with the applicable federal, state, or local plumbing codes.
Notice: Furnishing and installing drain lines is the responsibility of the Owner/Installer.
Notice: If additional drain is required (maximum length 12 feet), use at least 1 1/2” ID piping of an
appropriate schedule and of a material suitable for sustained operation at 140°F.
Notice: Joining clamps may be used to connect same size or larger size drain to the existing drain.
The following restrictions and requirements are critical to the safety of personnel and equipment,
and must not be violated under any circumstances:
1. Do not connect the MINI drain connection to any drain material that cannot sustain 140° F.
2. Do not connect drains from any other equipment to the drain line of the MINI.
