CF3000 - USER MANUAL
11
Sounders and Beacons
A wide range of loop powered sounders and beacons are available to operate with CF3000 consisting of
a combined sounder base with a maximum output of 95 dB(A), a standalone sounder with a maximum
output of 100 dB(A) that is available in standard or weatherproof versions and a stand alone loop
powered beacon.
For applications where a discreet dedicated sounder is required, a cover plate is available for the white
base mounted sounder enabling it to be used as a stand alone wall or ceiling mounted sounder.
All of these devices are fully programmable via the sophisticated CF3000 multi stage cause and effect
programming facilities.
All sounders have multiple selectable volume settings, the volume setting is controlled globally
by the CF3000 panel and so can be altered without needing to access the sounder. Alternatively
individual sounders can be set through the Cooper programming utility.
Base Sounder - FXN538LBS
The CAS380 has been designed specifically to complement the latest generation of Cooper soft
addressed detectors. it consists of a first fix bracket, and a main body which clips onto the bracket
incorporating the sounder and a detector mounting base in a single composite assembly.
After the body has been clicked into place and connected, a detector or front cover is then added to
complete a very simple quick and neat installation. The cover enables the CAS380 to be used as a
discreet stand alone wall or ceiling mounted device. The sounder base design incorporates a mechanism
that can be activated if required to lock either the detector or the cover into place to prevent unauthorised
removal.
Section 1 - System Installation and Design
Base sounder
CAS380
Base sounder with MASC fitted
CAS380
Base sounder with detector fitted
CAS380
