Copystar CS-1620 - Page 104

2C9-6.0
1-5-5
Feedshift
section
55 Misfeed in the feedshift
section* (paper feed from
second paper feeder)
The feedshift switch (FSSW) does not turn on within 6320 ms
of feedshift switch (FSSW) turning on.
The feedshift switch (FSSW) does not turn off within 1530 ms
of paper switchback.
The feedshift switch (FSSW) does not turn on within 1530 ms
of paper switchback.
56 Misfeed in the feedshift
section* (paper feed from
third paper feeder)
The feedshift switch (FSSW) does not turn on within 6320 ms
of feedshift switch (FSSW) turning on.
The feedshift switch (FSSW) does not turn off within 1530 ms
of paper switchback.
The feedshift switch (FSSW) does not turn on within 1530 ms
of paper switchback.
Duplex sec-
tion
60 Misfeed in duplex paper
conveying section*
The duplex paper conveying switch (DUPPCSW)* does not
turn off within 3280 ms of the feedshift switch (FSSW) turning
on.
The duplex paper conveying switch (DUPPCSW)* does not
turn on within 3280 ms of the feedshift switch (FSSW) turning
on.
The duplex paper conveying switch (DUPPCSW)* does not
turn off within 3280 ms of the feedshift switch (FSSW) turning
off.
61 Misfeed in duplex exit sec-
tion*
The registration switch (RSW) does not turn on within 1760 ms
of the duplex paper conveying switch (DUPPCSW)* turning
on.
The registration switch (RSW) does not turn off within 1760 ms
of the duplex paper conveying switch (DUPPCSW)* turning
off.
DP 70 No original feed* During the primary feed of the second original in the single-
sided or double-sided original mode, even if retry operation is
performed five times, primary original feed is not performed.
71 An original jam in the orig-
inal conveying section 1*
During the secondary original feed in the single-sided or dou-
ble-sided original mode, the DP timing switch (DPTSW)* does
not turn off within 6500 ms of the original conveying motor
(OCM)* turning on.
72 An original size error jam* During the secondary original feed in the single-sided or dou-
ble-sided original mode, the DP timing switch (DPTSW)* does
turn off within 750 ms of the original conveying motor (OCM)*
turning on.
73 An original jam in the orig-
inal conveying section 2*
During scanning of the second side or reversing of the original
for ejection in the double-sided original mode, the DP timing
switch (DPTSW)* does not turn off within 6500 ms of the origi-
nal conveying motor (OCM)* turning on.
74 An original jam in the orig-
inal conveying section 3*
During scanning of the second side or reversing of the original
for ejection in the double-sided original mode, the DP timing
switch (DPTSW)* does not turn on within 750 ms of the origi-
nal conveying motor (OCM)* turning on.
75 An original jam in the orig-
inal switchback section*
During the switchback operation of an original in the double-
sided original mode, the original switchback switch (OSBSW)
*does not turn on within 1300 ms of the original conveying
motor (OCM)* turning on.
*: Optional.
Section Jam code Description Conditions
