Copystar CS-1620 - Periodic Maintenance Procedures

2C9-3
2-4-9
Periodic maintenance procedures
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Test copy and
test print
Perform at the maxi-
mum copy size
Test copy Every service
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Paper feed
section
Paper feed pulley
Clean or replace - Clean with the alcohol. 1-6-5
Separation pulley
Clean or replace - Clean with the alcohol. 1-6-3
Forwarding pulley
Clean or replace - Clean with the alcohol. 1-6-5
Bypass paper feed pulley Clean or replace - Clean with the alcohol. 1-6-9
Bypass separation pad
Clean or replace - Clean with the alcohol. 1-6-9
Left registration roller
Clean or replace Every 150,000 counts Clean with alcohol or a dry cloth. 1-6-11
Right registration roller Clean
Every 150,000 counts Clean with alcohol or a dry cloth.
Registration cleaner Clean or replace Every 150,000 counts Vacuum. 1-6-11
Trans guide film
Clean or replace - 1-6-11
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Optical section Slit glass Clean
Every 150,000 counts Clean with alcohol and then a
dry cloth.
Contact glass Clean
Every 150,000 counts Clean with alcohol and then a
dry cloth.
Mirror 1 Clean - Clean with alcohol and then a
dry cloth only if vertical black
lines appear on the copy image.
Mirror 2 and mirror 3 Clean - Clean with alcohol and then a
dry cloth only if vertical black
lines appear on the copy image.
Lens Clean - Clean with alcohol and then a
dry cloth only if vertical black
lines appear on the copy image.
Reflector Clean - Clean with alcohol and then a
dry cloth only if vertical black
lines appear on the copy image.
Exposure lamp Clean or replace - Replace if an image problem
occurs or after the exposure
lamp does not turn on.
1-6-17
Optical rail Grease - Check noise and shifting and
then apply scanner rail grease
EM-50E..
Original size detection
sensor
Clean - Clean with alcohol or a dry cloth.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Transfer and
separation
section
Transfer roller Clean -
Vaccum or clean with a dry cloth. 1-6-37
Separation electrode
Check or clean - Clean with the equipped brush.
