Copystar CS-1620 - Page 232

2C9
2-4-10
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Developing
section
Developing unit
Check or replace - Replace if the problem occurs. 1-6-36
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Drum section Drum unit
Check or replace Every 150,000 counts Replace if the problem occurs. 1-6-33
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Fixing section Fixing unit
Check or replace - Replace if the problem occurs. 1-6-38
Heat roller Clean
Every 150,000 counts Clean with alcohol. 1-6-39
Press roller Clean
Every 150,000 counts Clean with alcohol. 1-6-42
Heat roller separation
claw
Clean or replace Every 150,000 counts Clean with alcohol. Replace if
it is being lacking, deforme d
or rubbing.
1-6-41
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Exit section Exit roller
Check or clean - Clean with alcohol or a dry cloth.
Exit pulley Check or clean - Clean with alcohol or a dry cloth.
Switchback roller Check or clean - Clean with alcohol or a dry cloth.
Switchback pulley Check or clean - Clean with alcohol or a dry cloth.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Covers Covers Clean
Every 150,000 counts Clean with alcohol or a dry cloth.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Other Image quality Check and adjust Every service
