Copystar CS-1620 - Page 211

2C9
2-3-7
Connector Pin No. Signal I/O Description
YC8 1 CCDO I CCDPCB image scanning signal
Connected
to the CCD
PCB
2 CCDON - Ground
3 CCDE I CCDPCB image scanning signal
4 CCDEN - Ground
5 +5 V O 5 V DC power supply for CCDPCB
6 S.GND - Ground
7 +12 V O 12 V DC power supply for CCDPCB
8 S.GND - Ground
9 CCDCLK O CCDCLK signal
10 S.GND - Ground
11 CCDCLKN O CCDCLKN signal
12 S.GND - Ground
13 RS O CCDPCB RS signal
14 S.GND - Ground
15 CP O CCDPCB CP signal
16 S.GND - Ground
17 SH O CCDPCB SH signal
18 S.GND - Ground
