Corghi 601 - Adhesive plates sticking

Operator’s manual @ 601 39
GB
Adhesive plates sticking
The machine is supplied with two adhesive plates. Before sticking them, make sure the
surfaces are dry, clean and free of dust.
Stick the @601 machine name adhesive plate in the position shown in figure 3 and the
machine data plate as shown in figure 4.
1
2
3 4
