Operator’s manual @ 601 53
GB
SELECTION OF FUNCTIONS
k1 k2 k3 k4
k1 If this lamp is on, the machine is set with adapters for motorcycle tyres or wheels
on which balancing weights cannot be applied on the sides.
k2 If this lamp is on, the machine is set with adapters for alloy rims on which the
balancing weights can be applied on the shoulder.
k2 If this lamp is on, the machine is set with adapters for alloy rims on which the
balancing weights can be applied on the external hidden side.
k4 If this lamp is on, the balancing weight can be applied on the external side and
fixed or inserted in the internal side of the rim.
All four lamps turned off indicates standard balancing. (When the measuring device is
activated, the computer automatically sets to that mode.)
COMPUTER SELD-DIAGNOSIS CODES
ERR -1-
Anomaly in the phase generator or power supply
card; the phase card is damaged or the phase con
nection line is interrupted
.
ERR -2-
Rotation speed is too low or the wheel has not been
mounted (with the tyre).
ERR -3-
Excessive unbalance, try another wheel
ERR -4-
Errors in the power system, rotation direction is not
correct.
ERR -5-
Lack of signal.
