Operator’s manual @ 601 45
GB
No. Item
Technical specifications Notes
16 Manual brake NO
Display on the
CPU
17 Display cover Packed separately
18 Display panel LCD
19 Distance setting Manual
20 CONE 3 chosen by customer
21 Balancing time 7 sec (16" standard rim) depending on the
wheel weight
22 Max. balancing speed 230 r/min depending on the
wheel weight
23 Balancing accuracy ± 1 g
24 Max. wheel width 20”
25 Max. wheel diameter 40”
26 Max. rim diameter 10”~24”
27 Max. rim width 1. 5”~20”
28 Max. wheel weight 70 kg
29 Dimensions (packing
included)
1050 x 710 x 1160 (L x W x H)
30 Machine weight 125 kg Net weight
31 Temperature 0°~40°
32 Humidity < 75%
33 Noise level < 70 dB
34 Resistance > 20 MW
35 Power Approx. 300W
36 Weight of electric/elec-
tronic parts
10 kg
