TROUBLE SHOOTING
IMPORTANT -- Only a service person should service internal components or
electrical wiring.
IMPORTANT -- If repairs are to be made to one of the syrup circuits, disconnect
applicable syrup tank and bleed pressure from the system before proceeding.
IMPORTANT -- If repairs will be made to the CO2 or carbonated water systems,
disconnect electrical power to the carbonator, shut off CO2 and water supplies,
then bleed systems before proceeding.
TROUBLESHOOTING POST-MIX SYSTEM
Trouble Probable Cause Remedy
Adjustment of dis-
pensing valve syrup
ow!regulator!does!
not increase to
desired water-to
syrup ratio.
1. No syrup supply.
2. Syrup supply container
not securely connected
into system.
3. Tanks System-Syrup
tanks secondary CO2
regulator out of adjust-
ment.
Bag-in-Box System-
Primary CO2 regulator
out of adjustment.
4. Inoperative dispensing
!!!!valve!syrup! ow!control.
5. Tapered washer inside
tube swivel nut connec-
tion distorted from being
over tightened restricting
!!!!syrup! o w.
1. Replenish syrup supply.
2. Securely connect syrup supply
container into syrup system.
3. Adjust syrup tanks secondary
CO2 regulator as instructed.
Adjust primary CO2 regulator as
instructed.
4. Repair dispensing valve syrup
!!!! ow!control.
5. Replace tapered gasket.
Make sure it seatsproperly.
Water and CO2 to the system must be turned off and the system depressurized prior to performing
this service.
Failure to comply could result in serious injury,death or damage to the equipment.
WARNING
Disconnect power to the unit before servicing following all lock out\tag out procedures established
by the user.Verify all power is off to the unit before performing any work.
Failure to comply could result in serious injury,death or damage to the equipment.
WARNING
