(PRELIMINARY) Operator’s Manual
© 2008, IMI Cornelius Inc. - 3 - Publication Number: 621260373OPR
SYSTEM OVERVIEW
The Viper is a Frozen Carbonated Beverage (FCB) unit. It delivers FCB and
FUB drinks from a single machine. The unit provides uniform, high quality, high
volume product to the customer. The unit has a refrigeration system for the
barrels, along with an intelligent defrost system for product quality.
The computerized beverage control system provides uniform, high-quality
product as well as diagnostic and troubleshooting information for the operator
and the service technician.
BEGINNING OPERATION
The control panel is located behind the merchandiser, above the dispensing
valves. It is accessed by lifting the merchaniser. See Figure 1Figure 1.
Figure 1
When the system is initially powered up, the screens in Figure 2 and Figure 3
are displayed temporarily as the unit goes through self-checks.
If either of these screens remains on, call service.
Figure 2
Control Panel
INITIALIZING
PLEASE STAND BY
FLASH:
EEPROM:
